* 页面的初始数据
*/
data: {
position: 'back', //摄像头的位置，有前置和后置
timeDelay: "15秒", //视频最大时长
countTimer: null, // 设置 定时器 初始为null
intervalNum: 15, //视频最大时长倒计时
initState: true, //初始化状态
isRecord: false, //是否正在录制
isFinish: false, //是否录制完成
startRecord: false, //是否开始录像，控制录像的默认状态，
videoSrc: '' //录像文件的位置
},
/**
* 生命周期函数--监听页面加载
*/
onLoad: function (options) {
//1-内层实体圆-白色-默认状态显示
var circleInnerCtx = wx.createCanvasContext('circleInnerLayer')
// 绘制图形
circleInnerCtx.arc(50, 50, 30, 0, 2 * Math.PI)
circleInnerCtx.setFillStyle('#EEEEEE')
circleInnerCtx.fill()
circleInnerCtx.draw()
//2-外层圆圈-白色-默认状态显示
var circleOuterCtx = wx.createCanvasContext('circleOuterLayer')
// 绘制图形
circleOuterCtx.arc(50, 50, 40, 0, 2 * Math.PI)
circleOuterCtx.setStrokeStyle('#EEEEEE')
circleOuterCtx.setLineWidth(5)
circleOuterCtx.stroke()
circleOuterCtx.draw()
//3-正方形-红色-录制视频时显示-与2不可能共存
var context = wx.createCanvasContext('circleRectLayer')
// context.fillRect(30, 30, 40, 40)
const pi = Math.PI;
const left = 30;
const top = 30;
const r = 10;
const width = 40;
const height = 40;
context.beginPath();
context.arc(left + r, top + r, r, -pi, -pi / 2);
context.arc(left + width - r, top + r, r, -pi / 2, 0);
context.arc(left + width - r, top + height - r, r, 0, pi / 2);
context.arc(left + r, top + height - r, r, pi / 2, pi);
context.closePath();
context.setFillStyle('red')
context.fill()
context.draw()
//4-绘制圆
//5-倒计时
},
/**录制视频时，外圈显示录制进度 */
recordingCanvas() {
this.setData({
isRecord: true,
})
// debugger
var totalTime = this.data.intervalNum;
this.data.countTimer = setInterval(() => {
if (totalTime > 0) {
//num++
totalTime--;
this.setData({
timeDelay: totalTime + "秒"
})
//context.moveTo(0,0)
//cxtProgress = wx.createCanvasContext('circleProgressLayer')
// context.rotate(-1 / 2 * Math.PI / 180);
cxtProgress.beginPath();
cxtProgress.arc(50, 50, 40, -Math.PI / 2, 2 * Math.PI * ((15 - totalTime) / 15) - Math.PI / 2)
//cxtProgress.arc(50, 50, 40, -1 / 2 * Math.PI, 3 / 2 * Math.PI * ((15 - totalTime) / 15))
cxtProgress.setStrokeStyle('red')
cxtProgress.setLineWidth(5)
cxtProgress.stroke()
cxtProgress.draw()
} else {
clearInterval(this.data.countTimer)
this.bindtouchend();
}
}, 1000)
},
bindtouchend(options) {
console.log("--bindtouchend");
if (this.data.isRecord) //已经开始录制视频时
{
clearInterval(this.data.countTimer) //清除计数器
this.clearCanvasRect(); //清除Canvas绘制的内容
this.stopRecord(); //停止录像
this.setData({
isFinish: true,
isRecord: false
})
},
//清除Canvas绘制的内容
clearCanvasRect() {
//清除画布上的所有内容
cxtProgress.clearRect(0, 0, wx.getSystemInfoSync().windowWidth, wx.getSystemInfoSync().windowHeight)
cxtProgress.draw()
},
|
